Masoneilan SVI2-31123111 SVI II AP Advanced Performance Digital Valve Positioner (HART)
| 起源の場所 | ドイツ |
|---|---|
| ブランド名 | Masoneilan |
| 証明 | / |
| モデル番号 | SVI2-31123111 |
| 最小注文数量 | 1個 |
| 価格 | USD 1980/PC |
| パッケージの詳細 | オリジナルの梱包 |
| 受渡し時間 | 5営業日 |
| 支払条件 | T/T |
| 供給の能力 | 1000pc/月 |
試供品およびクーポンのための私に連絡しなさい。
whatsapp:0086 18588475571
WeChat: 0086 18588475571
Skype: sales10@aixton.com
心配があれば、私達は24時間のオンライン・ヘルプを提供する。
x商品の詳細
| 信号-コミュニケーション | HART 5 または 7 4-20mA以上 | 建設 / 材料 | 銅のないアルミニウムホイジング |
|---|---|---|---|
| 動作温度 | -50°Cから+85°C | 重さ | 1個 |
製品の説明
-
The SVI™ II AP (Smart Valve Interface, Advanced Performance) is a 32 bit microprocessor digital valve positioner with a local interface that controls a pneumatic actuator using a two-wire 4-20mA control signal. The instrument offers bi-directional communication using the HART® protocol. Its universal design offers ease of retrofit in place of existing analog positioners on Masoneilan or non-Masoneilan pneumatic actuators, either single-acting or double-acting.
Features / Benefits :
Non-Contact Position Sensing Technology:
- Sensing through the housing, no mechanical moving parts entering the main housing cavity, prolonging the life
- Simple mounting procedure
Easy, Simple, Accurate:
- LCD and pushbuttons operable in all certified hazardous environments
- Quick and accurate commissioning with auto stops and auto tune methods
- One design fits many applications
- Rotary or Linear
- Remote or Local
Specifications
Signal - Communication
- HART 5 or 7 over 4-20mA
Diagnostics
- Standard Diagnostics
- Advanced Diagnostics
Construction / Materials
- Copper-free Aluminum Housing
Operating Temperature
- -50°C to +85°C
Pneumatics Action
- Single or Double Acting, fail safe
- Rotary and linear
Supply Pressure
• Single-Acting: 20 to 100 psi max (1.4 to 6.9 bar)
• Double-Acting: 20 to 150 psi max (1.4 to 10.3 bar)
Air Delivery
- 280 SLPM @ 30psi
Certification
- ATEX, IECEx, US, Canada approvals for
- Flameproof/Explosion-proof
- Intrinsic Safety
- Dust Ignition proof
- Non-Incendive
