Wenglor P1KK001 Retro-Reflex Sensor for Transparent Objects with 1500 mm Range and 2000 Hz Switching Frequency
| 起源の場所 | ドイツ |
|---|---|
| ブランド名 | Wenglor |
| 証明 | CCC,CE |
| モデル番号 | P1KK001 |
| 最小注文数量 | 1 |
| 価格 | $190 |
| パッケージの詳細 | オリジナルのパッケージ |
| 受渡し時間 | 5～8営業日 |
| 支払条件 | L/C、D/A、D/P、T/T |
| 供給の能力 | 1000個/月 |
商品の詳細
| 重さ | 6g | 温度範囲 | -40 ... 60°C |
|---|---|---|---|
| 頻度の切り替え | 2千 Hz | 電源電圧 | 10の… 30ボルトDC |
| 範囲 | 1,500のmm | ||
| ハイライト | Wenglor retro-reflex sensor transparent objects,Differential pressure gauge with warranty,P1KK001 sensor for transparent detection |
||
製品の説明
The retro-reflex sensor for transparent objects works with red light and a reflector. Where conventional retro-reflex light barriers reach their limits, this retro-reflective barrier for clear glass recognition ensures that extremely shiny objects like glass, PET bottles, trays or film can be detected. Via the single-lens optic without blind spots, the sensor can detect objects even through small holes and gaps. The IO-Link interface can be used to configure retro-reflective barriers (PNP/NPN, NC/NO, switching distance), as well as for reading out switching statuses and signal values.
